Abstract
This check provides raw data and visualizations to aid a user in evaluating whether the distribution of quantitative variables aligns with clinical expectations. It can summarize the distribution of a quantitative variable (like lab result values) or patient counts (like number of patients with an outpatient visit).
Data Requirements
Probe
Clinical Assessment
Access Package
# install.packages("devtools")
devtools::install_github('ssdqa/https://github.com/ssdqa/quantvariabledistribution')Visualization Output
This check displays the Euclidean distance between two time series: the smoothed (Loess) summary statistic as selected by the user for a given site and the all-site statistic. Three graphs are output:
- A line graph displaying the smoothed summary statistuc at each site over time, with the Euclidean distance available in the tooltip when hovering over the line
- A line graph displaying the raw (not smoothed) summary statistic at each site over time
- A circular bar graph displaying the Euclidean distance from the all-site value where the fill represents the average Loess statistic over time
Raw Output
This check produces a raw data output containing 12 columns:
| Column | Data Type | Definition |
|---|---|---|
site |
character | the name of the site being targeted OR “combined” if multiple sites were provided |
time_start |
date | the start of the time period being examined |
value_type |
character | the type of value being measured |
mean_val or median_val |
numeric | the mean or median of the value_type being measured, based on the user’s selection |
allsite_var |
numeric | the euclidean_stat of interest across all sites |
date_numeric |
numeric | the numeric equivalent of time_start |
site_loess |
numeric | the euclidean_stat value with Loess regression applied |
dist_eucl_mean |
numeric | the Euclidean distance of site_loess from allsite_var |
euclidean_stat |
character | the summary statistic selected by the user for the computation |
output_function |
character | a string indicating the type of visualization that should be generated by qvd_output |
